EE 140: Analog Integrated Circuits
This is a collection of links to lectures of Electrical Engineering 140: Analog Integrated Circuits from UC Berkeley Webcasts. Linear Integrated Circuits - Single and multiple stage transistor amplifiers. Operational amplifiers.
Feedback amplifiers, 2-port formulation, source, load, and feedback network loading. Frequency response of cascaded amplifiers, gain-bandwidth exchange, compensation, dominant pole techniques, root locus. Supply and temperature
independent biasing and references.
| Video/text |
EE 140: Analog Integrated Circuits (Spring 2014) |
|
Instructor: Professor Vladimir Stojanovic. BJT Small-signal Model and Biasing. MOSFET Operation. MOSFET Small-Signal Models. 1-Transistor MOSFET Amplifiers. Amplifier Frequency Analysis. Current Mirrors. Differential Pair Amplifiers. ... |
| Video/text |
EE 140: Analog Integrated Circuits (Fall 2013) |
|
Instructor: Professor Clark Tu-Cuong Nguyen. Device Models. Inspection Analysis. High Swing Current Sources. Current Source Matching. High Gain Op Amps. Stability. CMOS Op Amp Compensation. Feedback Configurations. Feedback by Inspection. ... |
| Video/text |
EE 140: Analog Integrated Circuits (Spring 2012) |
|
Instructor: Professor Clark Tu-Cuong Nguyen. Device Models. Inspection Analysis. Op Amps & Emitter Coupled Pair. High Gain Op Amps. CMOS Op Amp Compensation. Slew Rate, Settling Time, Power Supply Rejection Ratio (PSRR). ... |
| Video/text |
EE 140: Analog Integrated Circuits (Spring 2011) |
|
Instructor: Professor Clark Tu-Cuong Nguyen. Modeling the Bipolar Junction Transistor (BJT). BJT Small Signal Model. MOS Transistors. Frequency Response Inspection Analysis. High Swing Current Sources. Current Source Matching. ... |
